FuelPreview doesn't work if you follow the instructions on the Fuel website.
Hi - If you follow the docs here: http://rmod.lille.inria.fr/web/pier/software/Fuel/Version1.8/Documentation/F... The example in the docs does not work. FLAnalyzer>>#showPreview gives a dnu. If you run the example in the class comments of FLGraphViewBuilder you get another dnu when ROElement>>#addShape: is sent. Should it work on Pharo 1.3? Thanks Paul
Hi Paul, thank you, instructions were wrong because was loading #bleedingEdge. Now I fixed it, please use: (ConfigurationOfFuel project version: #static) load: 'FuelPreview'. HTH, Martin On Thu, Jun 7, 2012 at 7:47 PM, Paul DeBruicker <pdebruic@gmail.com> wrote:
Hi -
If you follow the docs here: http://rmod.lille.inria.fr/web/pier/software/Fuel/Version1.8/Documentation/F...
The example in the docs does not work.
FLAnalyzer>>#showPreview gives a dnu. Â If you run the example in the class comments of FLGraphViewBuilder you get another dnu when ROElement>>#addShape: is sent.
Should it work on Pharo 1.3?
Thanks
Paul
For viewing the example you sent in the other thread you may do: |coll| coll:=OrderedCollection new. (Interval from: 1 to: 100) do: [:each| coll add:( each \\ 2 = 0 ifTrue: [SortedCollection sortBlock:[:a :c | a name < c name] ] ifFalse:[Dictionary new] ) ]. (FLAnalyzer newDefault setDebug; analysisFor: coll) openPathsToEvery: [:o | o isKindOf: SortedCollection ]. Trick: in the case you want to explore the graph traced using FuelMetalevel, you should send #useFullMappers this way: (FLAnalyzer newDefault useFullMappers; setDebug; analysisFor: coll) openPathsToEvery: [:o | o isKindOf: SortedCollection ]. in this case I think will be the same, but in others may differ. FuelPreview is a very new tool, please tell us what can be improved. Cheers, MartÃn
That bit of code serializing the collection with SortedCollections and Dictionaries isn't something I'm using, its just recreated error that popped up when I was trying to sort out my initial problem. On 06/07/2012 04:53 PM, Martin Dias wrote:
in this case I think will be the same, but in others may differ.
FuelPreview is a very new tool, please tell us what can be improved.
Is there a way to prevent the drawing of lines between nodes that are: nil, true, false, Characters, Symbols, and SmallIntegers? Also for those values and maybe strings can the nodes just be 'nil' or 4 or $b whichever it may be instead of the black circles? When trying to visualize one of my domain objects the visualization looks like the attached. And I can't really tell what's going on. Thanks
Is there a way to prevent the drawing of lines between nodes that are:
nil, true, false, Characters, Symbols, and SmallIntegers?
Hhm ok, probably in most cases it's superfluous to see such basic objects.
Also for those values and maybe strings can the nodes just be 'nil' or 4 or $b whichever it may be instead of the black circles?
good idea
When trying to visualize one of my domain objects the visualization looks like the attached.
And I can't really tell what's going on.
Ouch, I know, that happens quite usually... Maybe Alexandre can help us to put another layout for the nodes? thanks MartÃn
