Now changed the variables in the generator.image for pointing to the right iPhoneOS SDK. Build process now complains... 0%] Building C object IOSPlugin/CMakeFiles/IOSPlugin.dir/Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c.o <built-in>:0: warning: Mac OS X version 10.5 or later is needed for use of the new objc abi <built-in>:0: error: Unknown value ‘6.1’ of -mmacosx-version-min Arhg Phil 2013/2/27 Igor Stasenko <siguctua@gmail.com>:

could be. Esteban didn't touched ios build for a while.. and there was some changes in cmake stuff meanwhile.

On 27 February 2013 17:02, phil@highoctane.be <phil@highoctane.be> wrote:

...

Guess the CMake that is generated is plain wrong.

/Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX6.1.sdk ...

WRONG I guess...

set(CMAKE_C_COMPILER /Applications/Xcode.app/Contents/Developer/Platforms/iPhoneOS.platform/Developer/usr/bin/gcc) set(CMAKE_CXX_COMPILER /Applications/Xcode.app/Contents/Developer/Platforms/iPhoneOS.platform/Developer/usr/bin/g++) set(CMAKE_OSX_ARCHITECTURES armv7) set(CMAKE_OSX_SYSROOT /) # This is automatically generated file using StackIPhoneConfig on 27 February 2013 4:17:00.984 pm cmake_minimum_required(VERSION 2.6.2) include(CMakeDetermineSystem) project("iStackVM") set(CMAKE_OSX_DEPLOYMENT_TARGET 10.5) set(CMAKE_OSX_SYSROOT /Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX6.1.sdk) include(directories.cmake) set(externalModulesDir "${outputDir}/iStackVM.app/Contents/MacOS/Plugins") message("${CMAKE_MODULE_PATH}") set(CMAKE_CONFIGURATION_TYPES Release) include_directories(${buildDir}/) include_directories(${platformsDir}/iOS/vm/iPhone) include_directories(${crossDir}/vm ${srcVMDir} ${targetPlatform}/vm ${buildDir}) include_directories(${srcDir}/vm) include_directories(${platformsDir}/iOS/vm/iPhone) include_directories(${platformsDir}/iOS/vm/iPhone/Classes) include_directories(${platformsDir}/iOS/vm/OSX) include_directories(${platformsDir}/unix/vm) include_directories(${platformsDir}/iOS/vm/Common/Classes) include_directories(${platformsDir}/iOS/plugins/SoundPlugin) include_directories(${platformsDir}/iOS/vm/OSX/plugins/SoundP

-- Best regards, Igor Stasenko.

It is beyond me why the fastest growing segment of hardware on the market is given substandard attention. And yes, Apple stuff rots fast indeed. Rotten Apple! Phil 2013/2/27 Igor Stasenko <siguctua@gmail.com>:

On 27 February 2013 17:46, phil@highoctane.be <phil@highoctane.be> wrote:

...

Now changed the variables in the generator.image for pointing to the right iPhoneOS SDK.

Build process now complains... 0%] Building C object IOSPlugin/CMakeFiles/IOSPlugin.dir/Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c.o <built-in>:0: warning: Mac OS X version 10.5 or later is needed for use of the new objc abi <built-in>:0: error: Unknown value ‘6.1’ of -mmacosx-version-min

Arhg

:)

Thanks, Phil for looking at it. Things rotting quite fast on Apple platforms.. so any external help is invaluable.

...

Phil

2013/2/27 Igor Stasenko <siguctua@gmail.com>:

...

could be. Esteban didn't touched ios build for a while.. and there was some changes in cmake stuff meanwhile.

On 27 February 2013 17:02, phil@highoctane.be <phil@highoctane.be> wrote:

...

Guess the CMake that is generated is plain wrong.

/Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX6.1.sdk ...

WRONG I guess...

set(CMAKE_C_COMPILER /Applications/Xcode.app/Contents/Developer/Platforms/iPhoneOS.platform/Developer/usr/bin/gcc) set(CMAKE_CXX_COMPILER /Applications/Xcode.app/Contents/Developer/Platforms/iPhoneOS.platform/Developer/usr/bin/g++) set(CMAKE_OSX_ARCHITECTURES armv7) set(CMAKE_OSX_SYSROOT /) # This is automatically generated file using StackIPhoneConfig on 27 February 2013 4:17:00.984 pm cmake_minimum_required(VERSION 2.6.2) include(CMakeDetermineSystem) project("iStackVM") set(CMAKE_OSX_DEPLOYMENT_TARGET 10.5) set(CMAKE_OSX_SYSROOT /Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX6.1.sdk) include(directories.cmake) set(externalModulesDir "${outputDir}/iStackVM.app/Contents/MacOS/Plugins") message("${CMAKE_MODULE_PATH}") set(CMAKE_CONFIGURATION_TYPES Release) include_directories(${buildDir}/) include_directories(${platformsDir}/iOS/vm/iPhone) include_directories(${crossDir}/vm ${srcVMDir} ${targetPlatform}/vm ${buildDir}) include_directories(${srcDir}/vm) include_directories(${platformsDir}/iOS/vm/iPhone) include_directories(${platformsDir}/iOS/vm/iPhone/Classes) include_directories(${platformsDir}/iOS/vm/OSX) include_directories(${platformsDir}/unix/vm) include_directories(${platformsDir}/iOS/vm/Common/Classes) include_directories(${platformsDir}/iOS/plugins/SoundPlugin) include_directories(${platformsDir}/iOS/vm/OSX/plugins/SoundP

-- Best regards, Igor Stasenko.

-- Best regards, Igor Stasenko.

when it cannot find standard headers, it means that sysroot is wrong. apparently: set(CMAKE_OSX_SYSROOT /Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX6.1.sdk should be different for iOS builds. But i cannot tell more. Esteban? On 27 February 2013 18:01, phil@highoctane.be <phil@highoctane.be> wrote:

Now, the thing has the right flags but still manages to complain about:

[PhilMac:~/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/build philippeback$] sudo make [ 0%] Building C object IOSPlugin/CMakeFiles/IOSPlugin.dir/Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c.o <built-in>:0: error: Unknown value ‘6.1’ of -mmacosx-version-min /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:10:18: error: math.h: No such file or directory /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:11:19: error: stdio.h: No such file or directory /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:12:20: error: stdlib.h: No such file or directory /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:13:20: error: string.h: No such file or directory /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:14:18: error: time.h: No such file or directory In file included from /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:25: /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/platforms/iOS/vm/iPhone/sqPlatformSpecific.h:68:20: error: unistd.h: No such file or directory In file included from /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:25: /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/platforms/iOS/vm/iPhone/sqPlatformSpecific.h:82: error: expected declaration specifiers or ‘...’ before ‘FILE’ /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/platforms/iOS/vm/iPhone/sqPlatformSpecific.h:132:22: error: pthread.h: No such file or directory /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c: In function ‘msg’: /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:110: warning: incompatible implicit declaration of built-in function ‘fprintf’ /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:110: error: ‘stderr’ undeclared (first use in this function) /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:110: error: (Each undeclared identifier is reported only once /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:110: error: for each function it appears in.) /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c: At top level: /Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c:170: error: ‘NULL’ undeclared here (not in a function) make[2]: *** [IOSPlugin/CMakeFiles/IOSPlugin.dir/Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c.o] Error 1 make[1]: *** [IOSPlugin/CMakeFiles/IOSPlugin.dir/all] Error 2 make: *** [all] Error 2

I'll work a tad more on this later today.

Phil

2013/2/27 Igor Stasenko <siguctua@gmail.com>:

...

On 27 February 2013 17:46, phil@highoctane.be <phil@highoctane.be> wrote:

...

Now changed the variables in the generator.image for pointing to the right iPhoneOS SDK.

Build process now complains... 0%] Building C object IOSPlugin/CMakeFiles/IOSPlugin.dir/Users/philippeback/Documents/Smalltalk/2-MyWorkspaces/workspaceVMiOSFromBook/blessed/src/plugins/IOSPlugin/IOSPlugin.c.o <built-in>:0: warning: Mac OS X version 10.5 or later is needed for use of the new objc abi <built-in>:0: error: Unknown value ‘6.1’ of -mmacosx-version-min

Arhg

:)

Thanks, Phil for looking at it. Things rotting quite fast on Apple platforms.. so any external help is invaluable.

...

Phil

2013/2/27 Igor Stasenko <siguctua@gmail.com>:

...

could be. Esteban didn't touched ios build for a while.. and there was some changes in cmake stuff meanwhile.

On 27 February 2013 17:02, phil@highoctane.be <phil@highoctane.be> wrote:

...

Guess the CMake that is generated is plain wrong.

/Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX6.1.sdk ...

WRONG I guess...

set(CMAKE_C_COMPILER /Applications/Xcode.app/Contents/Developer/Platforms/iPhoneOS.platform/Developer/usr/bin/gcc) set(CMAKE_CXX_COMPILER /Applications/Xcode.app/Contents/Developer/Platforms/iPhoneOS.platform/Developer/usr/bin/g++) set(CMAKE_OSX_ARCHITECTURES armv7) set(CMAKE_OSX_SYSROOT /) # This is automatically generated file using StackIPhoneConfig on 27 February 2013 4:17:00.984 pm cmake_minimum_required(VERSION 2.6.2) include(CMakeDetermineSystem) project("iStackVM") set(CMAKE_OSX_DEPLOYMENT_TARGET 10.5) set(CMAKE_OSX_SYSROOT /Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX6.1.sdk) include(directories.cmake) set(externalModulesDir "${outputDir}/iStackVM.app/Contents/MacOS/Plugins") message("${CMAKE_MODULE_PATH}") set(CMAKE_CONFIGURATION_TYPES Release) include_directories(${buildDir}/) include_directories(${platformsDir}/iOS/vm/iPhone) include_directories(${crossDir}/vm ${srcVMDir} ${targetPlatform}/vm ${buildDir}) include_directories(${srcDir}/vm) include_directories(${platformsDir}/iOS/vm/iPhone) include_directories(${platformsDir}/iOS/vm/iPhone/Classes) include_directories(${platformsDir}/iOS/vm/OSX) include_directories(${platformsDir}/unix/vm) include_directories(${platformsDir}/iOS/vm/Common/Classes) include_directories(${platformsDir}/iOS/plugins/SoundPlugin) include_directories(${platformsDir}/iOS/vm/OSX/plugins/SoundP

-- Best regards, Igor Stasenko.

-- Best regards, Igor Stasenko.

-- Best regards, Igor Stasenko.
