Hi Hannes, My detailed comments/answers below, after quoting 2 of your emails:

On 10 Dec 2015, at 22:17, H. Hirzel <hannes.hirzel@gmail.com> wrote:

Hello Sven

On 12/9/15, Sven Van Caekenberghe <sven@stfx.eu> wrote:

...

The simplest example in a common language is (the French letter é) is

LATIN SMALL LETTER E WITH ACUTE [U+00E9]

which can also be written as

LATIN SMALL LETTER E [U+0065] followed by COMBINING ACUTE ACCENT [U+0301]

The former being a composed normal form, the latter a decomposed normal form. (And yes, it is even much more complicated than that, it goes on for 1000s of pages).

In the above example, the concept of character/string is indeed fuzzy.

HTH,

Sven

Thanks for this example. I have created a wiki page with it

I wonder what the Pharo equivalent is of the following Squeak expression

$é asString asDecomposedUnicode

Regards

Hannes

You also wrote:

The text below shows how to deal with the Unicode e acute example brought up by Sven in terms of comparing strings. Currently Pharo and Cuis do not do Normalization of strings. Limited support is in Squeak. It will be shown how NFD normalization may be implemented.

Swift programming language -----------------------------------------

How does the Swift programming language [1] deal with Unicode strings?

// "Voulez-vous un café?" using LATIN SMALL LETTER E WITH ACUTE let eAcuteQuestion = "Voulez-vous un caf\u{E9}?"

// "Voulez-vous un café?" using LATIN SMALL LETTER E and COMBINING ACUTE ACCENT let combinedEAcuteQuestion = "Voulez-vous un caf\u{65}\u{301}?"

if eAcuteQuestion == combinedEAcuteQuestion { print("These two strings are considered equal") } // prints "These two strings are considered equal"

The equality operator uses the NFD (Normalization Form Decomposed)[2] form for the comparison appyling a method #decomposedStringWithCanonicalMapping[3]

Squeak / Pharo -----------------------

Comparison without NFD [3]

"Voulez-vous un café?" eAcuteQuestion := 'Voulez-vous un caf', 16rE9 asCharacter asString, '?'. combinedEAcuteQuestion := 'Voulez-vous un cafe', 16r301 asCharacter asString, '?'.

eAcuteQuestion = combinedEAcuteQuestion false

eAcuteQuestion == combinedEAcuteQuestion false

The result is false. A Unicode conformant application however should return *true*.

Reason for this is that Squeak / Pharo strings are not put into NFD before testing for equality =

Squeak Unicode strings may be tested for Unicode conformant equality by converting them to NFD before testing.

Squeak using NFD

asDecomposedUnicode[4] transforms a string into NFD for cases where a Unicode code point if decomposed, is decomposed only to two code points [5]. This is so because when initializing [6] the Unicode Character Database in Squeak this is a limitation imposed by the code which reads UnicodeData.txt [7][8]. This is not a necessary limitation. The code may be rewritten at the price of a more complex implementation of #asDecomposedUnicode.

"Voulez-vous un café?" eAcuteQuestion := 'Voulez-vous un caf', 16rE9 asCharacter asString, '?'. combinedEAcuteQuestion := 'Voulez-vous un cafe', 16r301 asCharacter asString, '?'.

eAcuteQuestion asDecomposedUnicode = combinedEAcuteQuestion asDecomposedUnicode

true

Conclusion ------------------

Implementing a method like #decomposedStringWithCanonicalMapping (swift) which puts a string into NFD (Normalization Form D) is an important building block towards better Unicode compliance. A Squeak proposal is given by [4]. It needs to be reviewed.extended.

It should probably be extended for cases where there are more than two code points in the decomposed form (3 or more?)

The implementing of NFD comparison gives us an equality test for a comparatively small effort for simple cases covering a large number of use cases (Languages using the Latin script).

The algorithm is table driven by the UCD [8]. From this follows an simple but important fact for conformant implementations need runtime access to information from the Unicode Character Database [UCD][9].

[1] https://developer.apple.com/library/ios/documentation/Swift/Conceptual/Swift... [2] http://www.unicode.org/glossary/#normalization_form_d [3] https://developer.apple.com/library/ios/documentation/Cocoa/Reference/Founda... [4] String asDecomposedUnicode http://wiki.squeak.org/squeak/6250 [5] http://www.unicode.org/glossary/#code_point [6] Unicode initialize http://wiki.squeak.org/squeak/6248 [7] http://www.unicode.org/Public/UNIDATA/UnicodeData.txt [8] Unicode Character Database documentation http://unicode.org/reports/tr44/ [9] http://www.unicode.org/reports/tr23/

Today, we have a Unicode and CombinedCharacter class in Pharo, and there is different but similar Unicode code in Squeak. These are too simple (even though they might work, partially). The scope of the original threads is way too wide: a new string type, normalisation, collation, being cross dialect, mixing all kinds of character and encoding definitions. All interesting, but not much will come out of it. But the point that we cannot leave proper text string handling to an outside library is indeed key. That is why a couple of people in the Pharo community (myself included) started an experimental, proof of concept, prototype project, that aims to improve Unicode support. We will announce it to a wider public when we feel we have something to show for. The goal is in the first place to understand and implement the fundamental algorithms, starting with the 4 forms of Normalisation. But we're working on collation/sorting too. This work is of course being done for/in Pharo, using some of the facilities only available there. It probably won't be difficult to port, but we can't be bothered with probability right now. What we started with is loading UCD data and making it available as a nice objects (30.000 of them). So now you can do things like $é unicodeCharacterData. => "U+00E9 LATIN SMALL LETTER E WITH ACUTE (LATIN SMALL LETTER E ACUTE)" $é unicodeCharacterData uppercase asCharacter. => "$É" $é unicodeCharacterData decompositionMapping. => "#(101 769)" There is also a cool GT Inspector view: Next we started implementing a normaliser. It was rather easy to get support for simpler languages going. The next code snippets use explicit code arrays, because copying decomposed diacritics to my mail client does not work (they get automatically composed), in a Pharo Workspace this does work nicely with plain strings. The higher numbers are the diacritics. (normalizer decomposeString: 'les élèves Français') collect: #codePoint as: Array. => "#(108 101 115 32 101 769 108 101 768 118 101 115 32 70 114 97 110 99 807 97 105 115)" (normalizer decomposeString: 'Düsseldorf Königsallee') collect: #codePoint as: Array. => "#(68 117 776 115 115 101 108 100 111 114 102 32 75 111 776 110 105 103 115 97 108 108 101 101)" normalizer composeString: (#(108 101 115 32 101 769 108 101 768 118 101 115 32 70 114 97 110 99 807 97 105 115) collect: #asCharacter as: String). => "'les élèves Français'" normalizer composeString: (#(68 117 776 115 115 101 108 100 111 114 102 32 75 111 776 110 105 103 115 97 108 108 101 101) collect: #asCharacter as: String). => "'Düsseldorf Königsallee'" However, the real algorithm following the official specification (and other elements of Unicode that interact with it) is way more complicated (think about all those special languages/scripts out there). We're focused on understanding/implementing that now. Next, unit tests were added (of course). As well as a test that uses http://www.unicode.org/Public/UNIDATA/NormalizationTest.txt to run about 75.000 individual test cases to check conformance to the official Unicode Normalization specification. Right now (with super cool hangul / jamo code by Henrik), we hit the following stats: #testNFC 16998/18593 (91.42%) #testNFD 16797/18593 (90.34%) #testNFKC 13321/18593 (71.65%) #testNFKD 16564/18593 (89.09%) Way better than the naive implementations, but not yet there. We are also experimenting and thinking a lot about how to best implement all this, trying out different models/ideas/apis/representations. It will move slowly, but you will hear from us again in the coming weeks/months. Sven PS: Pharo developers with a good understanding of this subject area that want to help, let me know and we'll put you in the loop. Hacking and specification reading are required ;-)
